New 2023 Harley-Davidson Pan America 1250 Special

View All Images Close
New 2023 Harley-Davidson Pan America 1250 Special
Pricing Details
Call for Price



Grand Canyon Harley-Davidson

12000, W Route 66 Bellemont, AZ 86015

Call Us: (928) 774-3896

Vehicle Saved!

New 2023 Harley-Davidson Pan America 1250 Special


Vehicle Details
  • Stock #: B302737
  • VIN: 1HD1ZES10PB302737
  • Mileage: 58
  • Exterior Color: BLACK
  • Location: Grand Canyon Harley Davidson

Test Ride
Get Pre-Approved
Value Your Trade

Similar Vehicles
Dimensions
  • Length: 2,270 mm
  • Seat Height, Unladen: 850 mm low; 875 mm high
  • Ground Clearance: 210 mm
  • Rake: 108 mm
  • Trail: 1,585 mm
  • Wheelbase: 120/70R19 60V
  • Tires, Front Specification: 170/60R17 72V
  • Tire, Type: Michelin™ Scorcher™ “Adventure”, Radial
  • Fuel Capacity: 21.2 l
  • Oil Capacity (w/filter): 4.5 l
  • Weight, As Shipped: 242 kg
  • Weight, In Running Order: 258 kg
Engine
  • Engine: Revolution™ Max 1250
  • Bore: 105 mm
  • Stroke: 72.3 mm
  • Displacement: 1,252 cc
  • Compression Ratio: 13.0:1
  • Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust: 2-into-1-into-1; catalyst in header
Performance
  • Engine Torque Testing Method: EC 134/2014
  • Engine Torque 3: 128 Nm
  • Engine Torque (rpm): 6750
  • Horsepower: 150 HP / 112 kW @ 8750 rpm
  • Lean Angle, Right (deg.): 42
  • Lean Angle, Left (deg.): 42
  • Fuel Economy Testing Method: EU 134/2014
  • Fuel Economy: 5.5 l/100 km
  • CO2 Emissions Testing Method: EU 134/2014
  • CO2 Emissions: 129 g/km CO2
Drivetrain
  • Primary Drive: Gear, 49/89 ratio
  • Gear Ratios (overall) 1st: 13.11
  • Gear Ratios (overall) 2nd: 9.687
  • Gear Ratios (overall) 3rd: 7.509
  • Gear Ratios (overall) 4th: 6.057
  • Gear Ratios (overall) 5th: 5.08
  • Gear Ratios (overall) 6th: 4.436
Chassis
  • Front Fork: 47mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps.
  • Rear Shocks: Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping
  • Wheels, Optional Style Type 4: Annodized aluminum tubeless laced
  • Wheels, Front Type 4: Aluminum cast, satin black
  • Wheels, Rear Type 4: Aluminum cast, satin black
  • Brakes, Rotor Type: Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
Electric
  • Lights (as per country regulation), Indicator Lamps: Daymaker Adaptive LED Headlamp with 6-segment LED banking lamp, LED Tail/Stop lamp with signature tail lighting, LED Bullet Turn Signals
  • Gauges: 6.8 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigation (H-D App ONLY)
Infotainment
  • Type: Color TFT w/ Touch
  • Screen Size: 173 mm
  • Headset Specifications (if equipped): Bluetooth
  • Languages: Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish (Mexico/Spain), Swedish, Thai, Turkish, Vietnamese
  • Hands-free Mobile Phone - via Bluetooth: Standard
  • Voice Recognition Languages: Phone functions only: Phone dependent
  • Voice Recognition Languages: Tuner/Media/Navigation: Phone dependent
  • Text-to-Speech (TTS) Languages: Phone dependent
  • Rider/Passenger Intercom: Headset function only
  • Vehicle Information Screen (Air temperature, oil pressure and EITMS): TPMS, Engine temp, Battery Voltage, Ambient Air Temp
  • USB: Charging and Instrument update, USB-C, 5V, 3A
  • Bluetooth: Phone/Media Supported
Rider Safety Enhancement
  • Anti-lock Brake System (ABS): Included
  • Electronic Linked Braking (ELB): Included
  • Traction Control System (TCS): Included
  • Drag-torque Slip Control System (DSCS): Included
  • Vehicle Hold Control (VHC): Included
  • Tire Pressure Monitoring System (TPMS): Included
  • Wheel Lift Mitigation: Included
  • Cornering Enhanced Anti-lock Brake System (C-ABS): Included
  • Cornering Enhanced Electronic Linked Braking (C-ELB): Included
  • Cornering Drag-Torque Slip Control System (C-DSCS): Included
  • Enhanced Lift Mitigation: Included
